AMF AMF lock case 141UNIG-30PZ DIN left / right ( 3000251248 )
Scope of Delivery: - Lock case 141UNIG-30PZ DIN left / right Product Description: with galvanised lock (143UNIG) - stainless steel, polished - 240 grit - stainless steel faceplate, polished - nickel-plated latch and deadbolt - can be used left and right due to reversible latch head - prepared for profile cylinder or BB (with retrofit kit) - backset 40 mm - distance 72 mm - square 8 mm - 1-turn - latch 2 mm protruding - deadbolt 3 mm protruding - accessories: - 2 lever handle rosettes 18 mm - 4 screws, stainless steel Technical Data: - Dimension B: 60mm - Dimension C: 166mm - Dimension A: 30mm - Square: 8mmFor commercial use, please observe the building regulations!
-
AMF AMF Screw jack no. 6400 ( 4000833112 ) Size 50 Height 38 - 50 mm
Sat, 09/20/2025
Scope of Delivery: - 1x AMF screw jack size 50 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 25kN - Centre hole Ø: 12mm - H max.: 50mm - D2: 31mm - TR: 20 x 4mm - H min.: 38mm - D1: 31mm - Size: 50 - Brand: AMF - Feature: with flat support - Height: 38 - 50 mm - Model: No. 6400Please observe the building regulations for commercial use!For commercial use, please observe the building regulations!
€37,18
-
AMF AMF screw-in support no. 6400 ( 4000833113 ) size 52 height 42 - 52 mm
Sat, 09/20/2025
Scope of Delivery: - 1x AMF screw jack size 52 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 100kN - Centre hole Ø: 12mm - H max.: 52mm - D2: 50mm - TR: 30 x 4mm - H min.: 42mm - D1: 50mm - Size: 52 - Brand: AMF - Feature: with flat support - Height: 42 - 52 mm - Model: No. 6400Please observe the building regulations for commercial use!For commercial use, please observe the building regulations!
€46,85
-
AMF AMF screw-in support no. 6400 ( 4000833114 ) size 70 height 50 - 70 mm
Sat, 09/20/2025
Scope of Delivery: - 1x AMF screw jack size 70 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 100kN - Centre hole Ø: 12mm - H max.: 70mm - D2: 50mm - TR: 30 x 4mm - H min.: 50mm - D1: 50mm - Size: 70 - Brand: AMF - Feature: with flat support - Height: 50 - 70 mm - Model: No. 6400For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
€49,41
-
AMF AMF screw-in support no. 6400 ( 4000833115 ) size 100 height 70 - 100 mm
Sat, 09/20/2025
Scope of Delivery: - 1x AMF screw jack size 100 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 100kN - Centre hole Ø: 12mm - H max.: 100mm - D2: 50mm - TR: 30 x 4mm - H min.: 70mm - D1: 50mm - Size: 100 - Brand: AMF - Feature: with flat support - Height: 70 - 100 mm - Model: No. 6400For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
€55,12
-
AMF AMF screw-in support no. 6400 ( 4000833116 ) size 140 height 100 - 140 mm
Sat, 09/20/2025
Scope of Delivery: - 1x AMF screw jack size 140 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 120kN - Centre hole Ø: 12mm - H max.: 140mm - D2: 68mm - TR: 40 x 7mm - H min.: 100mm - D1: 68mm - Size: 140 - Brand: AMF - Feature: with flat support - Height: 100 - 140 mm - Model: No. 6400For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
€91,61
-
AMF AMF screw-in trestle no. 6400 ( 4000833117 ) size 210 height 140 - 210 mm
Scope of Delivery: - 1x AMF screw jack size 210 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 170kN - Centre hole Ø: 12mm - H max.: 210mm - D2: 70mm - TR: 50 x 8mm - H min.: 140mm - D1: 80mm - Size: 210 - Brand: AMF - Feature: with flat support - Height: 140 - 210 mm - Model: No. 6400Please observe the building regulations for commercial use!For commercial use, please observe the building regulations!
-
AMF AMF screw-in support no. 6400M ( 4000833476 ) size 80 height 60 - 80 mm
Scope of Delivery: - 1x AMF screw jack size 80 Product Description: with flat support and magnetic base - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - the permanent magnet can be used to achieve precise positioning of the workpiece in a vertical position - Ø specification = without magnetic base Technical Data: - Max. load capacity: 100kN - Centre hole Ø: 12mm - H max.: 80mm - D2: 50mm - TR: 30 x 4mm - H min.: 60mm - D3: 55mm - D1: 50mm - Size: 80 - Brand: AMF - Feature: with flat support and magnetic base - Height: 60 - 80 mm - Model: No. 6400MPlease observe the building regulations for commercial use!For commercial use, please observe the building regulations!
-
AMF AMF screw-in support no. 6430S Atlas ( 4000833127 ) size 140 height 100 - 140 mm
Sat, 09/20/2025
Scope of Delivery: - 1x AMF screw jack size 140 Product Description: with lock nut - spindle complete: heat-treated steel, with trapezoidal thread - burnished spindle head - base body: grey cast iron, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function reliably and precisely even under the heaviest loads Technical Data: - B1: 18mm - B2: 75mm - Max. load capacity: 60kN - Centre hole Ø: 12mm - H max.: 140mm - L: 110mm - TR: 30 x 6mm - H min.: 100mm - Width across flats: 46mm - Size: 140 - Brand: AMF - Feature: with locknut - Height: 100 - 140 mm - Model: No. 6430S AtlasFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
€97,75
-
AMF AMF screw-in trestle no. 6430S Atlas ( 4000833128 ) size 200 height 140 - 200 mm
Scope of Delivery: - 1x AMF screw jack size 200 Product Description: with lock nut - spindle complete: heat-treated steel, with trapezoidal thread - burnished spindle head - base body: grey cast iron, painted - the robust design means that the screw jacks with infinitely variable adjustability function reliably and precisely even under the heaviest loads Technical Data: - B1: 18mm - B2: 75mm - Max. load capacity: 60kN - Centre hole Ø: 12mm - H max.: 200mm - L: 110mm - TR: 30 x 6mm - H min.: 140mm - Width across flats: 46mm - Size: 200 - Brand: AMF - Feature: with locknut - Height: 140 - 200 mm - Model: No. 6430S AtlasFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
-
AMF AMF screw-in trestle no. 6430S Atlas ( 4000833130 ) size 320 height 200 - 320 mm
Sat, 09/20/2025
Scope of Delivery: - 1x AMF screw jack size 320 Product Description: with lock nut - spindle complete: heat-treated steel, with trapezoidal thread - burnished spindle head - base body: grey cast iron, painted - the robust design means that the screw jacks with infinitely variable adjustability function reliably and precisely even under the heaviest loads Technical Data: - B1: 22mm - B2: 90mm - Max. load capacity: 40kN - Centre hole Ø: 12mm - H max.: 320mm - L: 160mm - TR: 30 x 6mm - H min.: 200mm - Width across flats: 46mm - Size: 320 - Brand: AMF - Feature: with locknut - Height: 200 - 320 mm - Model: No. 6430S AtlasFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
€165,00
-
AMF AMF screw-in support attachment no. 6440 Insert spigot Ø 12 mm ( 4000833135 )
Sat, 09/20/2025
Scope of Delivery: - Screw-in trestle attachment no. 6440 Insert spigot Ø 12 mm Product Description: Ball - suitable for screw brackets with 12 mm centre hole - hardened and tempered steel - burnished finish Technical Data: - Insertion spigot Ø: 12mm - D: 37mm - H: 10mmFor commercial use, please observe the building regulations!
€18,28
