Scope of Delivery:
- 1x BENNING multimeter 0.000 V -1000 V AC/DC
- Delivery incl. rubber protection frame with magnetic hanger, bag, battery (9 V block LR 61), test leads Spare battery see art. no. 4000 876 104
Product Description:
with illuminated 4-digit LCD display (6000 dots) with bar graph - continuity test via red LED and buzzer - diode test - AutoV function for automatic AC/DC voltage detection - low input impedance LoZ for suppression of capacitive/inductive interspersed voltages - integrated voltage sensor contactlessly signals phase voltages and cable breaks in lines (optical/acoustic) - single-pole phase test - automatic range selection - automatic switch-off - measured value (HOLD), peak value memory (PEAK), relative measurement (REL) - measurement category CAT IV 600 V, CAT III 1000 V Measurement ranges: DC voltage: 100 µV - 1000 V, AC voltage: 100 µV - 1000 V, DC current: 1 mA - 10 A, AC current: 20 mA - 10 A, Resistance: 0.1 Ω - 40 MΩ, Frequency: 0.01 Hz - 100 kHz, Capacitance: 1 nF - 10 mF
Technical Data:
- Width: 82mm
- Length: 163mm
- Height: 50mm
- Measuring method: TRUE RMS
- Brand: BENNING
- Nominal voltage range: 0.000 V -1000 V AC/DC
- Measuring category: CAT IV 600 VNote on the disposal of batteries and rechargeable batteries As we sell batteries and rechargeable batteries or devices containing batteries and rechargeable batteries, we are obliged under the Battery Act (BattG) to draw your attention to the following: The symbol of the crossed-out dustbin on batteries or accumulators means that they must not be disposed of with household waste after use. If batteries or accumulators contain mercury, cadmium or lead, you will find the respective chemical symbol (Hg, Cd or Pb) below the symbol of the crossed-out dustbin. Every user of batteries or accumulators is legally obliged to return old batteries and accumulators. You can do this free of charge at a retail outlet or other collection point in your area. You can obtain the addresses of suitable collection centres in your area from your city or local authority. For batteries that contain more than 0.0005 per cent mercury by mass, more than 0.002 per cent cadmium by mass or more than 0.004 per cent lead by mass, the chemical designations of the pollutant used can be found under the waste bin symbol. The chemical designations have the following meaning: Pb: Battery contains lead Cd: Battery contains cadmium Hg: Battery contains mercuryFor commercial use, please observe the building regulations!
For commercial use, please observe the building regulations!
