Scope of Delivery:
- 1x PFERD flap disc Ø30xH10mm grit size 60
Product Description:
Aluminium oxide A - with flaps made of abrasive on backing - for universal use from coarse to fine sanding - shaft Ø 6 mm
Technical Data:
- Shank Ø: 6mm
- Drive type: Flexible shaft drive, straight grinder
- Application recommendation: The stock removal rate should be increased by using a coarser grit and not by increasing the contact pressure in order to prevent unnecessary tool wear and thermal stress on the workpiece. Increasing the cutting speed results in a slightly finer surface finish. Increasing the contact pressure results in a slightly coarser surface. The softer the material to be machined, the coarser the surface (when using , Reducing the contact pressure and the peripheral speed and adding grinding oil reduce tool wear and the temperature load on the workpiece. For best performance, use at a recommended cutting speed of 15-20 m/s. This achieves an ideal compromise between stock removal rate, surface finish, temperature load on the workpiece and tool wear. Use a suitable grinding oil for the material to significantly increase the service life and grinding performance of the tools.
- Machinable materials: Steels up to 1,200 N/mm² ( 54 HRC, malleable cast iron, aluminium
- Machining tasks: Weld seam processing, surface processing, structuring (matting, line matting and satin finishing), levelling, fine grinding in stages, deburring
- Width: 10mm
- Note: PFERDERGONOMICS recommends flap discs in order to sustainably reduce the vibration and noise generated during use and to improve working comfort.
- Length, shaft: 40mm
- RPM, opt.: 12000RPM
- Safety instructions: For safety reasons, the specified maximum permissible speed must never be exceeded. The contact pressure must be significantly reduced if the specified optimum speed is exceeded. Safety is only guaranteed if the clamping length is at least 15 mm and the specified maximum speed is not exceeded with open shank lengths.
- Advantages: Optimum contour adaptation due to high flexibility. Consistently high material removal rate over the entire service life, as new, aggressive abrasive is constantly released. Can be used very close to edges and at angles thanks to the flat cast core design.
- grit size: 60
- Max. speed: 25400 min-¹
- Abrasive: Aluminium oxide A
- Material suitability Aluminium: limited suitability
- Material suitability cast iron: very suitable
- Material suitability steel: very suitable
- Brand: PFERD
- Material: Aluminium oxide
- Ø: 30 mm
- Height: 10 mm
- Material suitability plastic: limited suitabilityPlease observe the building regulations for commercial use!
