Scope of Delivery:
- 1x RIDGID inspection camera Cable length 25 m Camera head Ø 15.5 mm
- Inspection kit with 25 metre connection cable and two guide balls Digital inspection camera and adapter are not included in the scope of delivery - please order separately (see item no. 4000 829 775)
Product Description:
ideally suited for inspection applications over longer distances with small diameters - the small 15.5 mm camera head diameter and a tight turning circle of the camera, as well as the ultra-flexible push cable, enable inspections even in 25 mm (1 inch) pipes with tight bends, up to a length of 25 metres - as a rule, the camera can be used from a pipe diameter of 30 mm with 90° bends (depending on the type and condition of the pipe) - the compact unit can be transported and stored easily and space-savingly - integrated stand offers versatility in use and improved stability - integrated 512 Hz transmitter enables easy location. - Compatible with SeeSnake monitors through the standard connection cable
Technical Data:
- Cable length metres: 25 Cable diameter mm: 7.2 for cables mm: 25-50 Resolution: 510 x 496 (PAL) Item no. 4000 829 888: Adapter with docking handle required for 4000 829 887 and use of the CA-350Technical data:
- Width: 22.5cm
- Length: 33.7cm
- Weight: 5.5kg
- Cable Ø: 7.2mm
- subject to testing: yes
- Height: 44.1cm
- Model: NANOreel
- Working range: 20 - 50 mm
- Cable length: 25 m
- Push cable length: 25 m
- Transmitter: 512 Hz
- Transmitter power: low, 1 m
- Camera head Ø: 15.5 mm
- Video resolution: 510 x 496 (PAL)
- Display resolution: 510 x 496
- Guide balls: 1
- Push cable Ø: 7.2 mm
- for pipe Ø: 25 - 50 mm
- Version: with transmitter
- Brand: RIDGIDFor commercial use, please observe the building regulations!
For commercial use, please observe the building regulations!
